Tub Filling Semi Automatic Machine
Semi automatic tub filling machine for multi flavour sundae
ice cream in plastic tubs.
Model : STFP
Our Semi Automatic Tub Filling Machine can filled Ingredients like nuts, chocolate chips and syrups like chocolate and other flavours mix with variety of ice creams in Sundae Tub gives attractive flower looks..
Features
Basic Functions
Chocolate spray
Filling
Chocolate Topping
Dry nut topping – Manual
Lid Placing – Manual
Cone crimping
Specifications
Machine Type
Semi Automatic Table Type
Product
Ice cream (2 in 1 Ice cream , with ripple , with ingredients by purchasing required attachments )
Application
To fill ice cream in to tubs as per requirement
Output Capacity
Up to 1200 cones/hr & Up to 2000 cups/hr
Filling
By Continuous Freezer
Filling Accuracy
Depends on the output of continuous freezer
Ingredient Size
8 x 8 x 8 mm for better distribution
PLC
Crouzet
Pneumatic Parts
Festo
Power Requirement
0.3 kw
Air Supply
Approximately 100-liter/minute at 6 bar at maximum speed
Base Structure
S.S. square pipe
Side Guard
S.S. 304
Panel
S.S. 304
Contact parts
Food grade material or S.S. 304
Base
Adjustable Ball feet
