IC60 PS Cups & Cones
Automatic high speed cup & cone ice cream filling & sealing machine.
Model : IC60 PS
Backed by rich industry experience, Our Rotary driven, Double Head Filling, Single Track with double indexing (Ratchet type) automatic Ice cream Cups & Cones Filling machine gives accuracy, speed and flexibility when handling cream, powders and granules. Its stainless-steel construction, easy-to-remove tooling and hopper allow for simple cleaning and maintenance with latest techniques in compliance with set industry standards.
Our Rotary Type Filling Machines for Ice-Cream Cups & Cones, Curd, Yogurt, Lassi, Ghee, Shrikhand, Chees, Ketchup etc.
Features
Basic Functions
* Customisations for additional stations are possible.
Automatic Cup / Cone Release
Sensing
Chocolate Spray
Filling
Chocolate Topping
Dry Nut Topping
Automatic Lid Placing
Cone Crimping
Ejecting
Specifications
Machine Type
Rotary machine, double head filling, single track with double indexing ( ratchet type ) and ( servo driven cam indexing type - optional )
Product
Ice cream ( 2 in 1 ice cream, with ripple, with ingredients by purchasing required attachments )
Application
To fill and pack ice cream in cups / cones
Output Capacity
700 to 3000 pcs / hour ( Up to 7000 pcs/hr in servo driven model )
Filling
By continuous freezer
Filling Accuracy
Depends on the output of continuous freezer
Ingredient Size
8 x 8 x 8 mm for better distribution
Round Cup
Max 80mm Æ, 75mm height
Round Cone
Max 60mm Æ, 150mm height
PLC
Allen Bradley Make
HMI
Allen Bradley Make
Pneumatic Parts
Festo
Power Requirement
1.8 kw
Air Supply
Approximately 1400-liter/minute at 6 bar at maximum speed
Base Structure
S.S. square pipe
Side guard
S.S. 304
Panel
S.S 304
Contact parts
Food grade material or S.S. 304
Base
Adjustable Ballfeet
